QF Manual Diverter Valve

Nordfab’s QF® Manual Diverter Valves provide a high efficiency, economical method of diverting the flow of material or air.

  • Constructed of heavy 3/16” thick, painted black metal, with welded seams. Supplied with heavy duty flange bearings, and rubber seal in door.
  • 45º angle only.
  • Reverse flow available upon request.
  • Available in carbon steel and 304SS (as shown below) or optional 316SS
  • Available with flanged ends in diameters up to 24", and other various end types
  • Optional collar material gauges 18, 16, 14 and 12

Contact Nordfab or your local Nordfab dealer for assistance with material / end type options.

Request a Quote
Download our Manual Diverter Valve Product Data sheet
Download our QF Manual Diverter Valve Revit® families





ø A in Material Thickness Length (in) Weight (lbs) Legacy Item No. Item No.
3 MS 3/16" 26 15 3235-0345-400000‍ 8010003130‍
4 MS 3/16" 26 20 3235-0445-400000‍ 8010003131‍
5 MS 3/16" 27.25 30 3235-0545-400000‍ 8010003132‍
6 MS 3/16" 28 44 3235-0645-400000‍ 8010003133‍
7 MS 3/16" 28 60 3235-0745-400000‍ 8010003134‍
8 MS 3/16" 29 67 3235-0845-400000‍ 8010003136‍
9 MS 3/16" 34 86 3235-0945-400000‍ 8010003138‍
10 MS 3/16" 36 100 3235-1045-400000‍ 8010003101‍
11 MS 3/16" 36 115 3235-1145-400000‍ 8010003103‍
12 MS 3/16" 40 130 3235-1245-400000‍ 8010003105‍
13 MS 3/16" 40 147 3235-1345-400000‍ 8010003107‍
14 MS 3/16" 44 170 3235-1445-400000‍ 8010003109‍
15 MS 3/16" 44 190 3235-1545-400000‍ 8010003111‍
16 MS 3/16" 48 220 3235-1645-400000‍ 8010003113‍
17 MS 3/16" 48 337 3235-1745-400000‍ 8010003115‍
18 MS 3/16" 52 392 3235-1845-400000‍ 8010003117‍
19 MS 3/16" 447 3235-1945-400000‍ 8010003119‍
20 MS 3/16" 60 447 3235-2045-400000‍ 8010003121‍
21 MS 3/16" 523 3235-2145-400000‍ 8010003123‍
22 MS 3/16" 61.25 523 3235-2245-400000‍ 8010003125‍
23 MS 3/16" 625 3235-2345-400000‍ 8010003127‍
24 MS 3/16" 68 625 3235-2445-400000‍ 8010003129‍
3 304SS 3/16" 26 15 3235-0345-200000‍ 8010003093‍
4 304SS 3/16" 26 20 3235-0445-200000‍ 8010003094‍
5 304SS 3/16" 27.25 30 3235-0545-200000‍ 8010003095‍
6 304SS 3/16" 28 44 3235-0645-200000‍ 8010003096‍
7 304SS 3/16" 28 60 3235-0745-200000‍ 8010003097‍
8 304SS 3/16" 29 67 3235-0845-200000‍ 8010003098‍
9 304SS 3/16" 34 86 3235-0945-200000‍ 8010003099‍
10 304SS 3/16" 36 100 3235-1045-200000‍ 8010003078‍
11 304SS 3/16" 36 115 3235-1145-200000‍ 8010003079‍
12 304SS 3/16" 40 130 3235-1245-200000‍ 8010003080‍
13 304SS 3/16" 40 147 3235-1345-200000‍ 8010003081‍
14 304SS 3/16" 44 170 3235-1445-200000‍ 8010003082‍
15 304SS 3/16" 44 190 3235-1545-200000‍ 8010003083‍
16 304SS 3/16" 48 220 3235-1645-200000‍ 8010003084‍
17 304SS 3/16" 48 337 3235-1745-200000‍ 8010003085‍
18 304SS 3/16" 52 392 3235-1845-200000‍ 8010003086‍
19 304SS 3/16" 447 3235-1945-200000‍ 8010003087‍
20 304SS 3/16" 60 447 3235-2045-200000‍ 8010003088‍
21 304SS 3/16" 523 3235-2145-200000‍ 8010003089‍
22 304SS 3/16" 61.25 523 3235-2245-200000‍ 8010003090‍
23 304SS 3/16" 625 3235-2345-200000‍ 8010003091‍
24 304SS 3/16" 68 625 3235-2445-200000‍ 8010003092‍
