Nordfab's FB Segmented Bends (15°) allow airflow direction change in a run of a duct and is easily connected to other duct components using FB Clips, which can be secured around the 6 mm flat edge on each end.
FB Segmented Bends are also available in 90°, 60°, 45°, and 30° angles.
- Galvanised steel construction with steel thickness 0,9 mm
- Radius = 1.5 x D
- Available in sizes Ø 350 - 1000 mm, see item numbers below
The FB Duct System is used in dust collection, process ventilation, and fume extraction systems in a wide variety of industries. Nordfab FB Ducting features a flat edge on the connecting ends.
| ø A (mm) | Angle degree | Center line radius | Material | T mm | Weight(kg) | Item No. |
|---|---|---|---|---|---|---|
| 350 | 15 | 1.5 | Galv | 0,9mm | 1,23 | 8210002963 |
| 400 | 15 | 1.5 | Galv | 0,9mm | 1,68 | 8210002968 |
| 450 | 15 | 1.5 | Galv | 0,9mm | 2,31 | 8210002973 |
| 500 | 15 | 1.5 | Galv | 0,9mm | 3,29 | 8210002978 |
| 550 | 15 | 1.5 | Galv | 0,9mm | 3,6 | 8210002983 |
| 600 | 15 | 1.5 | Galv | 0,9mm | 3,78 | 8210002988 |
| 630 | 15 | 1.5 | Galv | 0,9mm | 3,98 | 8210002993 |
| 650 | 15 | 1.5 | Galv | 0,9mm | 4,18 | 8210002998 |
| 700 | 15 | 1.5 | Galv | 0,9mm | 4,47 | 8210003003 |
| 750 | 15 | 1.5 | Galv | 0,9mm | 4,77 | 8210003008 |
| 800 | 15 | 1.5 | Galv | 0,9mm | 5,16 | 8210003013 |
| 850 | 15 | 1.5 | Galv | 0,9mm | 5,48 | 8210003018 |
| 900 | 15 | 1.5 | Galv | 0,9mm | 5,8 | 8210003023 |
| 950 | 15 | 1.5 | Galv | 0,9mm | 6,13 | 8210003028 |
| 1000 | 15 | 1.5 | Galv | 0,9mm | 6,44 | 8210003033 |
